PULS Power Supplies was founded in 1980 by Bernhard Erdl in Munich, Germany. PULS is the only company worldwide that is focused on the production and development of DIN Rail Power Supplies. Puls power supplies offer high efficiency, low heat dissipation, easy to use connection features, and state of the art protective devices.

Output currents from 1 to 40 amps (25-960 watts).  PULS power supplies are available in single-phase and three-phase input models.  Puls also manufactures diode isolation units, buffers, semi-regulated power supplies, AC/DC converters, and UPS systems.

Excel Automation is an authorized stocking PULS distributor.  Contact us for sales & application assistance for our Puls power supplies.

  Puls Power Supplies Overview Video

The Puls Competitive Advantage



View or download the PULS Product Catalog here.

PULS Power Supply Data Sheets

PULS Power Supplies Data Sheets
Dimension Q-Series Single & 3-Phase Power Supplies (very thin profile)
Output Voltage Amps Watts Phase Input Voltage Part # Purchase
12-15 VDC 15A 180W 1PH 100-240 VAC purchase
24-28 VDC 3.4A 80W 1PH 100-240 VAC QS3.241 purchase
5A 120W 1PH 100-240 VAC QS5.241 view product
10A 240W 1PH 100-240 VAC QS10.241 view product
20A 480W 1PH 100-240 VAC QS20.241 view product
20A 480W 3PH 380-480 VAC QT20.241 view product
28-32 VDC 8.6A 240W 1PH 100-240 VAC QS10.301 view product
36-42 VDC 13.3A 240W 1PH 100-240 VAC QS20.361 view product
13.3A 240W 3PH 380-480 VAC QT20.361 view product
48-56 VDC 5A 240W 1PH 100-240 VAC QS10.481 view product
10A 480W 1PH 100-240 VAC QS20.481 view product
10A 480W 3PH 380-480 VAC QT20.481 view product
Dimension Q-Series (Device Net Power Supplies)
24 VDC 3.8 A 91W 1PH 100-240 VAC QS5.DNET view product
24 VDC 8A 192W 1PH 100-240 VAC QS10.DNET view product
Dimension Q-Series : DC/DC Converter for Drive Systems
24-28 VDC 20A 480W 360-600 VDC QTD20.241 view product
Dimension C-Series Single Phase Power Supplies  (very thin profile)
24-28 VDC 3A 72W 1PH 100-240VAC CS3.241 view product
5A 120W 1PH 100-120/208-240VAC CS5.241 view product
10A 240W 1PH 100-120/208-240VAC CS10.241 view product
10A 240W 1PH 100-120/208-240VAC CS10.242 view product
48-56 VDC 5A 240W 1PH 100-120/208-240VAC CS10.481 view product
Dimension Y-Series De-coupling Modules (diodes)
10-60VDC 20A use with Q-Series Power Supplies YR2.DIODE view product
volt in = 2 x 10-60
20A use with C-Series Power Supplies YRM2.DIODE view product
vot in = 2 x 24-60VDC
Dimension X-Series 3-Phase Semi-regulated Power Supplies
24VDC 40A 960W 3PH 480VAC XT40.242 view product
36VDC 26.6A 960W 3PH 480VAC XT40.362 view product
48VDC 20A 960W 3PH 480VAC XT40.482 view product
72VDC 13.3A 960W 3PH 480VAC XT40.722 view product
Dimension U-Series DC-UPS Controller Only : 1 External 12V Battery Required
22.3VDC 10A external battery required : 3.9-28Ah UB10.241 view product
volt in from power supply : 24-28.8VDC
volt in from battery : 12VDC
Dimension U-Series DC-UPS with 1 Internal 12V Battery Included
22.3VDC 10A internal battery included : 5Ah UBC10.241 view product
volt in from power supply : 24-28.8VDC
volt in from battery : 12VDC
Dimension U-Series Batteries & Battery Mounting Kits
12VDC 5Ah battery only (for use w/UBC10.241) UZB12.051 view product
7Ah battery w/mounting kit (for use w/UB10.241) UZK12.071 view product
7Ah battery only (for use w/UB10.241) UZB12.071 view product
mounting kit only (for use w/UB10.241) UZO12.07 view product
26Ah battery w/mounting kit (for use w/UB10.241) UZK12.261 view product
battery only (for use w/UB10.241) UZB12.261 view product
mounting kit only (for use w/UB10.241) UZO12.26 view product
Dimension U-Series Buffer Modules (capacitors)
24-28.8VDC 20A 24-28.8VDC UF20.241 view product
48-56VDC 20A 48-56VDC UF20.481 view product
Dimension Z-Series Mounting Kits
PANEL MOUNT all Dimension (C, Q, U, X, & Y Series) ZM1.WALL view product
SIDE MOUNT CS3, CS5, QS3, YR2.diode & YRM2.diode ZM11.SIDE view product
SIDE MOUNT QS5 ZM12.SIDE view product
SIDE MOUNT CS10 & QS10 ZM13.SIDE view product
SIDE MOUNT QT20 & UF20 ZM14.SIDE view product
Miniline ML-Series Low Power Single Phase Power Supplies
5-5.5VDC 5A 25W 1PH 100-240VAC ML30.101 view product
10-12VDC 3.0A 30W 1PH 100-240VAC ML30.102 view product
12-15VDC 4.2A 50W 1PH 100-240VAC ML50.102 view product
7.5A 90W 1PH 100-120/208-240VAC ML100.102 view product
+/-12 OR +/-15VDC 1.4-2.8A 36W 1PH 100-240VAC ML30.106 view product
24-28VDC 1.3A 30W 1PH 100-240VAC ML30.100 view product
2.1A 50W 1PH 100-240VAC ML50.100 view product
2.1A 50W 1PH 100-240VAC ML50.101 view product
2.1A 50W 1PH 100-240VAC ML50.111 view product
3.0A 72W 1PH 100-120/208-240VAC ML70.100 view product
3.9A 95W 1PH 100-120/208-240VAC ML95.100 view product
4.2A 100W 1PH 100-120/208-240VAC ML100.100 view product
48-56VDC 1.05A 50W 1PH 100-240VAC ML50.105 view product
2.1A 100W 1PH 100-120/208-240VAC ML100.105 view product
Miniline ML-Series Power Supplies – for use with 480VAC 3-Phase Sysytem
24-28VDC 3.75A 90W 2PH 380-480VAC ML90.200 view product
4.2A 100W 2PH 380-480VAC ML100.200 view product
Miniline ML-Series De-coupling Module (diodes)
10-60VDC 10A 2 x 10-60VDC MLY02.100 view product
Silverline SL-Series Single & 3-Phase Power Supplies
12-15VDC 3A 40W 1PH 100-120/208-240VAC SL2.103 view product
15A 180W 1PH 100-120/208-240VAC SL10.104 view product
24VDC 2.5A 60W 1PH 100-120/208-240VAC SL2.100 view product
4A 96W 1PH 100-120/208-240VAC SL4.100 view product
5A 120W 1PH 100-120/208-240VAC SL5.100 view product
24-28VDC 5A 120W 1PH 100-120/208-240VAC SL5.102 view product
5A 120W 1PH 100-120/208-240VAC SL5.105 view product
10A 240W 1PH 100-120/208-240VAC SL10.100 view product
10A 240W 1PH 100-120/208-240VAC SL10.105 view product
20A 480W 1PH 100-120/208-240VAC SL20.110 view product
20A 480W 1PH 100-120/208-240VAC SL20.111 view product
20A 480W 1PH 100-120/208-240VAC SL20.115 view product
30A 720W 1PH 208-240VAC SL30.100 view product
36-43VDC 13.3A 480W 1PH 100-120/208-240VAC SL20.112 view product
46-56VDC 5A 240W 1PH 100-120/208-240VAC SL10.101 view product
5A 240W 1PH 100-120/208-240VAC SL10.106 view product
10A 480W 1PH 100-120/208-240VAC SL20.113 view product
24-28VDC 5A 120W 3PH 380-480VAC SL5.300 view product
10A 240W 3PH 380-480VAC SL10.300 view product
20A 480W 3PH 480VAC SL20.301 view product
20A 480W 3PH 380-480VAC SL20.310 view product
30A 720W 3PH 380-480VAC SL30.300 view product
40A 960W 3PH 380-480VAC SL40.300 view product
40A 960W 3PH 380-480VAC SL40.301 view product
48-52VDC 5A 240W 3PH 380-480VAC SL10.305 view product
Silverline SL-Series Redundancy Power Supplies w/Integreated De-coupling Diodes
24VDC 2.5A 60W 1PH 100-120/208-240VAC SLR2.5 view product
5A 120W 1PH 100-120/208-240VAC SLR5.100 view product
10A 240W 1PH 100-120/208-240VAC SLR10.100 view product
Silverline SL-Series De-coupling modules (diodes)
24-28VDC 30A 2 x 24-28VDC SLR02 view product
40A 24-28VDC SLR01 view product
Silverline SL-Series Buffer Modules (capacitors)
22.5-27.8VDC 20A 480W 24-28.8VDC SLV20.200 view product
Silverline SL-Series DC/DC Converter
5.1VDC 8A 40W 18-36VDC SLD2.100 view product
Silverline SL-Series AS-Interface Power Supplies
30.5VDC 2.8A 85W 1PH 100-120/208-240VAC SLA3.100 view product
4A 122W 1PH 100-120/208-240VAC SLA4.100 view product
8A 244W 1PH 100-120/208-240VAC SLA8.100 view product
8A 244W 3PH 380-480VAC SLA8.300 view product
Silverline SL-Series Mounting Kits
Panel Mount all Silverline : adds 22mm to the width of P.S. SLZ02 view product
S7 300 DIN Rail all SL-2 models : width = 51mm SLZ11 view product
all SL-5 Single Phase models : width = 66mm SLZ12 view product
SL5.300 & SL10.300 models : width = 90mm SLZ13 view product
all SL10 Single Phase models : width = 121mm SLZ14 view products

 Excel Automation is a PULS power supply authorized stocking distributor.

Visit our shopping cart for on-line ordering or contact us for technical, application or sales assistance.

Ph: 330-220-1977






Puls power supplies

Excel Automation is a PULS power supply authorized stocking distributor.  Below are some of the top benefits of using our Puls power supplies:

EFFICIENCY

  • PULS power supplies have the highest energy efficiency in the market (up to 97%)
  • Less heat generated in the enclosure allows a longer lifetime for all components in the system
  • Least energy consumption for the user

BROAD PRODUCT RANGE

  • AC single, 3-Phase and DC input power supplies
  • AC to DC power converters
  • Specific Network power supplies
  • Redundancy modules & Redundant power supplies
  • DC-UPS controllers with individual battery monitoring & charging

LOWEST TOTAL COST OF OWNERSHIP

  • PULS power supplies small footprints result in smaller cabinet requirements
  • Lower heat generation also leads to smaller cabinets
  • PULS power supplies long life prolongs replacement costs
  • Less energy consumed to due the same job

QUALITY & LIFETIME

  • PULS power supplies have the longest life in the industry
  • Quality is assured with every PULS power supply product
  • Performance to data sheets is guarenteed

LONG LIFE OF PRODUCT FAMILIES

  • PULS is continually introducing the next generation of DC power solutions while maintaining existing designs
  • PULS does not phase out or obsolete standard products
  • Eliminates the forced changes to your design and enclosures due to obsolescence
  • Availability you can count on for years

PULS – THE DC POWER SPECIALISTS

  • DC power products are the only business PULS is in
  • Market education and training leader
  • PULS Data sheets that you can rely on to meet stated performance

PULS – THE TECHNOLOGY LEADER

  • Advanced design techniques utilized to lead the market in new product innovations
  • PULS was recognized by Frost & Sullivan as the technology leader

CUSTOMER SERVICE & APPLICATION ASSISTANCE

  • Application engineering support available to assist you with the best product for your application
  • Excel Automation is a technical authorized stocking distributor available to for sales and application assistance
  • Same day shipping from Excel Automation on in-stock items

CONTROL OF SUPPLY CHAIN & MANUFACTURING

  • From development to shipment the entire process is controlled by PULS
  • Two ultra-modern facilities opened in the last 5 years
  • Significant stocking inventory at Excel Automation

DEVELOPMENT ENGINEERING RESOURCES

  • PULS employees over 50 engineers and technicians  exclusively dedicated to developing DC power products for your application
  • Modified standard products availalbe for volume applications



Excel Automation is an PULS authorized stocking distributor.

Visit our on-line shopping cart for ordering, or contact us for technical, application & sales support.

PH: 330-220-1977
